Mathematics
Advanced
50 mins
Teacher/Student led
+80 XP
Teacher-led from the board. Pupils do not need a device, but can follow on one.
What you need:
IWB/Projector/Large Screen
Multilink cubes

Volume of Cubes and Cuboids

Learn to find the volume of cubes and cuboids using length × breadth × height, connect it to the area of the base multiplied by height, and work backwards to find a missing dimension from a known volume.

Teacher Class Feed

Load previous activity
    Your turn
    Your teacher is running this lesson on the board. Here is the part you can try yourself.
    Shape measurer

    1 - Getting Started ~4 mins

    Illustration for Getting StartedLook at the picture on the board: an empty box, with a pile of little centimetre cubes beside it.

    Roughly how many of those little cubes do you think would fill the box right up to the top? Have a good look before you guess.

    2 - Watch and Notice ~9 mins

    Three boxes come up on the board, one after another, each already filled with little centimetre cubes: a box 5 cm long, 3 cm wide and 2 cm high; a box 6 cm long, 4 cm wide and 3 cm high; and last a cube with every side 4 cm. Watch how the number of cubes grows each time.

    For each box, count one flat layer of cubes first. Then count how many layers are stacked up. One layer, times the number of layers, gives the whole box.

    The last box is a plain cube: every side is the same length. Together, tell me what happens to the count when all three sides are the same length.

    3 - Try It Together ~8 mins

    We build and measure at the board together. Whoever is at the board drags the sliders while the whole class works each answer out loud.

    First set the box to 3 × 2 × 2. Then grow it to 5 × 4 × 2. Then raise the height to 3 cm.

    Each time, work out the base layer first, then how many layers high the box is, and call out your prediction before we read the volume off the tool.

    Shape Measurer

    4 - Sketch the Cuboids in Your Copy ~2 mins

    COPYBOOK MOMENT

    In your maths copy, sketch these three shapes: the 5 × 3 × 2 box, the 6 × 4 × 3 box, and the 4 cm cube.

    Label the three dimensions on each one, then write the volume formula and the answer in cm³. Underline the unit on every one.

    Pupil practice
    Module 5 · Measures: Length, Area, Volume, Mass and Capacity Measures
    Lesson 58 · Volume of Cubes and Cuboids
    Download Activity Book page (PDF)
